The PF15ECE features a dreadnought body with a Venetian cutaway and a laminated spruce top on mahogany back and sides with a high gloss finish. The round soundhole has a black and white acrylic rosette and a black pickguard. The mahogany neck has a 20-fret rosewood fingerboard with small white dot position markers. Components include a compensated plastic saddle in a rosewood bridge with ivory Ibanez Advantage bridge pins, a plastic nut, and chrome Ibanez tuning machines. Electronics consist of an Ibanez under saddle pickup connected to an AEQ200T preamp with on-board tuner powered by a 9V battery and a 1/4″ stereo end-pin output jack.
Model: PF15ECE-NT
SPECIFICATIONS
| body shape |
Cutaway Dreadnought body |
| top |
Spruce top |
| back & sides |
Okoume back & Okoume sides |
| neck |
PF/Nyatoh neck |
| fretboard |
Laurel fretboard |
| bridge |
Laurel bridge |
| inlay |
White dot inlay |
| soundhole rosette |
Black & White multi |
| tuning machine |
Chrome Die-cast tuners |
| number of frets |
20 |
| bridge pins |
Ibanez Advantage™ |
| strings |
Ibanez IACS6C |
| string gauge |
.012/.016/.024/.032/.042/.053 |
| string space |
11mm |
| factory tuning |
1E,2B,3G,4D,5A,6E |
| pickup |
Ibanez Undersaddle |
| preamp |
Ibanez AEQ-2T preamp w/Onboard tuner |
| output jack |
1/4" output |
